Quality Douglas® Premier™ XS Tennis Posts, 2-7/8″ OD
Quality Douglas® Premier™ XS Tennis Posts, 2-7/8″ OD
SKU: 63034
Couldn't load pickup availability



- Description
- Additional Info
- Support Documents
Description
The Premier™ XS Series is the Cadillac of tennis posts; providing first-class looks and durability for both indoor and outdoor court applications.
DIMENSIONS 60” in length and sit 42” above court surface
POST These 2-7/8” OD posts are constructed from heavy-duty 8-gauge steel and feature Allied’s® superior Flo-coat® galvanization process. Posts are finished with black or green baked-on polyester powder coat to resist rust and increase durability. Integrated welded steel lacing rods are included for a professional net installation.
HARDWARE Internally wound posts feature a jam-free cable tensioning hardware system. Choose from plated steel, stainless steel or brass gears. Gear housings and caps are made of die cast zinc. The gear function is 30:1 ratio to ensure a smooth, easy operation. The flush mounted gear plate cover has a removable handle to prevent any unwanted tampering.
WARRANTY 5 Year Limited
GROUND SLEEVES Corresponding 24″ ground sleeves are sold separately. Choose from PVC or Aluminum.




Additional Info
Support Documents
Type | File |
---|---|
Bid Specs | Douglas-Spec-PREMIER-XS-Tennis-Posts.pdf |
CAD Drawings | 2763-007-Douglas-Industries-Inc.-Douglas_-Premier_-XS-Tennis-Post.pdf |
Cut Sheets | 630323334SSBR-Douglas-Premier-XS-Tennis-Post.pdf |
Installation Instructions | Douglas-Install-Premier-XS-Tennis.pdf |
Literature | Douglas_Tennis_Posts_Nets_20.pdf |
